DC Fast EV Charger CSD R2
60kW–360kW DC Fast EV Charger | Dual Connector High-Power Charging Station for Commercial Use
Quick Information
Ultra-Fast DC Charging
Dual Connector Support
User-Friendly Touch Interface
Smart Connectivity & Protocols
High-Accuracy Energy Metering
Durable Outdoor Design
Certified & Compliant
Wide Environmental Tolerance
| Category | Item | Specification |
|---|---|---|
| power input | Input Type | 3-phase |
| Input Wiring Scheme | 3P+N+PE | |
| Rated Voltage | 400VAC±15% | |
| Max. THDI | 5% | |
| Min. Power Factor | 98% | |
| Grid Frequency | 50Hz or 60Hz | |
| Power output | Output voltage | 150∼1000VDC |
| Maximum Current | 200A / 250A / 300A | |
| Rated Power | 60–360kW | |
| User interface | Charge Connector | CCS2 / CCS1 / GB/T / CHAdeMO |
| No. of connector | 2 | |
| Cable length | 5m or Optional | |
| LED indicator | Green / Blue / Red, Progress Indicator | |
| LCD display | 7″ Touch Color Screen | |
| RFID Reader | ISO/IEC 14443 RFID Card | |
| User interface | Backend | Standard: Ethernet / 4G |
| Charging protocol | OCPP 1.6J | |
| Safety and certification | Energy Metering | Meter with 1% Accuracy |
| Ingress Protection | IP54 | |
| Impact Protection | IK10 | |
| Cooling method | Fan cooling | |
| Electrical Protection | Over/Under Voltage Protection, Over Current Protection, Short Circuit Protection, Over/Under Temperature |
|
| Electrical Protection (cont.) | Lightning Protection, Ground Protection |
|
| Certification | CE, RoHS | |
| Certification and conformity | IEC 61851-1, IEC 62196-1/-2 | |
| Environment | Mounting | Floor standing |
| Storage Temperature | -40°C∼+75°C | |
| Operating Temperature | -30°C∼+50°C | |
| Max Operating Humidity | 95%, non-condensing | |
| Max Operating Altitude | 2000m | |
| Mechanical | Product dimension | 750×600×1800 mm |
| Package Dimension | 117×82×198 cm / 295 kg 120×90×65 cm / 85 kg |
|
| Accesory | N/A |
CSD-R2 DC Fast Charging Station (60kW–360kW)
Commercial-grade DC fast charger supporting 60kW to 360kW output, up to 300A/1000V, designed for all modern EVs including buses and trucks.
Equipped with dual charging connectors (CCS2, CCS1, GBT, or CHAdeMO), 7″ touchscreen, RFID reader, and energy metering with ±1% accuracy.
OCPP 1.6J protocol supported, Ethernet/4G connectivity, IP54 & IK10 rated for outdoor durability.
Key Features
Ultra-Fast Charging Power
Output power from 60kW to 360kW, 150–1000V DC voltage range, up to 300A current for rapid charging.
Output power from 60kW to 360kW, 150–1000V DC voltage range, up to 300A current for rapid charging.
Dual Connector Support
Flexible connector configuration (CCS1, CCS2, GBT, CHAdeMO) allows simultaneous dual-EV charging.
Flexible connector configuration (CCS1, CCS2, GBT, CHAdeMO) allows simultaneous dual-EV charging.
7″ Smart Touchscreen
Easy-to-use interface with LED indicators, real-time charging status, and RFID card reader (ISO/IEC 14443).
Easy-to-use interface with LED indicators, real-time charging status, and RFID card reader (ISO/IEC 14443).
Advanced Communication
Supports OCPP 1.6J and backend control via Ethernet or 4G for remote monitoring and billing.
Supports OCPP 1.6J and backend control via Ethernet or 4G for remote monitoring and billing.
Built-in Smart Meter
±1% accurate metering for energy usage tracking and transparent billing.
±1% accurate metering for energy usage tracking and transparent billing.
Durable Outdoor Design
IP54 waterproof, IK10 impact protection, fan cooling for reliable 24/7 operation.
IP54 waterproof, IK10 impact protection, fan cooling for reliable 24/7 operation.
Certified & Compliant
CE, RoHS certified; complies with IEC61851-1, IEC62196-1/2 for global market access.
CE, RoHS certified; complies with IEC61851-1, IEC62196-1/2 for global market access.
Wide Environmental Tolerance
Operating temperature: -30°C to +50°C; supports deployment up to 2000m altitude.
Operating temperature: -30°C to +50°C; supports deployment up to 2000m altitude.
Application Scenarios
Highway Charging Stations
Ideal for expressway rest stops and service zones offering ultra-fast charging to travelers and fleets.
Ideal for expressway rest stops and service zones offering ultra-fast charging to travelers and fleets.
Urban Charging Hubs
Efficient fast-charging in high-density areas like city centers and transit terminals.
Efficient fast-charging in high-density areas like city centers and transit terminals.
Commercial Parking Areas
Add value for businesses by enabling premium EV charging at shopping malls, business parks, etc.
Add value for businesses by enabling premium EV charging at shopping malls, business parks, etc.
Fleet Depots
Optimized for e-buses, logistics vans, taxis, and ride-hailing platforms.
Optimized for e-buses, logistics vans, taxis, and ride-hailing platforms.
EV Dealerships & Service Bays
Used for test-drive preparation, quick-charging during maintenance, or vehicle delivery.
Used for test-drive preparation, quick-charging during maintenance, or vehicle delivery.
Smart Energy Projects
Integrates with solar, battery storage, and energy management platforms for sustainable charging.
Integrates with solar, battery storage, and energy management platforms for sustainable charging.
